LGCY series trailer mounted air Equipment is extensively used in mining, water conservancy, traffic, shipbuilding, civil construction, energy, and military industries. In Europe and the United States and other developed countries, portable air Equipment for power refers to screw air Equipment for 100%.
Trailer Mounted Air Equipment Mainly Has the Following Advantages:
1. Low operating sound and less vibration design. Easy serviceability.
2. Low fuel consumption to realize far distance outdoor usage;Full protection system,energy saving.
3. High efficient Air end:
Large diameter rotor, airend connect with diesel engine through coupling and no reduction gear inside, more reliability, the rotate speed is same with the diesel engine’s, more longer lifespan.
4. Diesel Engine of Famous Brand:
Select the diesel engine of COMMINS and YUCHAI brand, satisfy the emission requirement of Europe, low oil consumption, after sale service system all over China.
5. Good adaptability:
The Portable Air Equipment automatically control the air delivery of diesel engine by matching the demand of air consumption, which equals to frequency conversion control in motor power screw air Equipment.
Diesel portable screw air Equipments are widely used in highways, railways, mines, water conservancy, and shipbuilding, urban construction, energy, military and other industries.
| Model | Working pressure | Capacity | Power | Dimension | ||||
| bar | psi | m³/min | cfm | model | KW | hp | mm | |
| LGCY-12/15T | 15 | 218 | 12 | 430 | Yuchai | 118 | 160 | 3000*1520*2200 |
| LGCY-15/16T | 16 | 232 | 15 | 540 | Yuchai | 140 | 190 | |
| LGCY-15/16TK | 16 | 232 | 15 | 540 | Cummins | 132 | 180 | |
| LGCY-17/17T | 17 | 247 | 17 | 612 | Yuchai | 162 | 220 | |
| LGCY-17/17TK | 17 | 247 | 17 | 612 | Cummins | 155 | 210 | |
| LGCY-18/20T | 20 | 290 | 18 | 648 | Yuchai | 191 | 260 | 3980*1800*2650 |
| LGCY-18/20TK | 20 | 290 | 18 | 648 | Cummins | 191 | 260 | 3980*1800*2650 |
| LGCY-19.5/19 | 19 | 276 | 19.5 | 696 | Cummins 6CTA8.3-C260 | 195 | 260 | |
| LGCY-19.5/19A | 19 | 276 | 19.5 | 696 | Yuchai YC6M260L-K20 | 3980*1800*2650 | ||
| LGCY-19/21-21/18 | 21 | 305 | 19 | 684 | Yuchai | 191 | 260 | 4600*1950*2850 |
| LGCY-19/21-21/18K | 21 | 305 | 19 | 684 | Cummins | 191 | 260 | 4600*1950*2850 |
| LGCY-21/21-23/18 | 21 | 305 | 21 | 756 | Yuchai | 228 | 310 | 4600*1950*2850 |
| LGCY-22/20 | 20 | 290 | 22 | 786 | Cummins 6CTA8.9-C325 | 240 | 325 | 4600*1950*2650 |
| LGCY-22/20 | 20 | 290 | 22 | 786 | Yuchai YC6MK340L-K20 | 250 | 340 | |
| LGCY-23/23-25/18 | 23 | 334 | 23 | 828 | Yuchai | 250 | 340 | |
| LGCY-23/23-25/18K | 23 | 334 | 23 | 828 | Cummins | 240 | 325 | |
| LGCY-27/23-29/18 | 23 | 334 | 27 | 972 | Yuchai | 294 | 400 | |
| LGCY-25/23-27/18K | 23 | 334 | 25 | 900 | Cummins | 265 | 360 | |
| LGCY-26/25 | 25 | 363 | 26 | 928 | Cummins QSZ13-C500 or Yuchai YC6K550L | 368 | 500 | 4700*2100*2500 |
| LGCY-26/25A | 25 | 363 | 26 | 928 | ||||
| LGCY-21/35 | 35 | 508 | 21 | 750 | ||||
| LGCY-26/25(21/35) | 25(35) | 363(508) | 26(21) | 929(750) | ||||
| LGCY-33/25 | 25 | 363 | 33 | 1179 | Cummins QSZ13-C550 or Yuchai YC6K550L | 405 | 550 | |
| LGCY-26/35 | 35 | 508 | 26 | 929 | ||||
| LGCY-29/25 | 25 | 363 | 39 | 1393 | Cummins KTA19-P630 or Caterpillar C-18ACERT | 463 | 630 | |
| LGCY-33/35 | 35 | 508 | 33 | 1179 | ||||
| LGCY39/25(33/35) | 25(35) | 363(508) | 39(33) | 1393(1179) | ||||
| LGCY-43/25-35/35Y | 25 | 363 | 43 | 1548 | Yuchai | 558 | 750 | 5000*2200*2900 |
Kaishan’s other products:
Truck-mounted Diesel Equipment for Water Well Drilling Rig
You can also check for Kaishan’s rock drilling rigs & DTH drill bits and hammers on our website:
WHY KAISHAN’s TROLLEY MOUNTED AIR EquipmentS?
Best-in-class energy efficiency
Best-in-class maintenance and operating cost
Best-in-class reliability, works in demanding work sites
Select models available with international warranty on engines
Easy manoeuvrability
Tow bars designed for safe highway running
Industrial grade steel and powder coated canopy for maximum corrosion protection and durability
Indigenously designed Neuron control system offering operating data and safety measures
Applicable Industries
Cable Laying construction Sites, mining sand blasting ,cbm (coal Bed Methane)oil & Gas Exploration.
